Top-class LED Display Manufacturer in China. services more than 120 countries around the world!
2 Years
| Ask Lasest Price | |
| Model Number : | TS-4.8 |
| Brand Name : | TEWEI |
| Supply Ability : | 4000 Set/Sets per Month |
| Price : | Negotiation |
| Certification : | CE RoHS ISO9001 UL FCC CCC |
| Delivery Time : | 20-25 days |
Full Color High Resolution Custom Rental LED Display/Screen/Video Wall Tewei P2 P3 P4 P4.8
Features
1, Seamless connection.
2, Special design for the mask to realize higher contrast and
larger viewing angle.
3, Signal backup and power backup.
4, Brightness and chromaticity calibration.
| Model | 2.6o | 2.9o | 3.9o | 4.8o |
| Pixel Pitch(mm) | P2.6 | P2.9 | P3.9 | P4.8 |
| Pixel Density(dot/㎡) | 147,456 | 112,896 | 65,536 | 43,264 |
| LED Type | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| Module Size(mm*mm) | 250*250 | 250*250 | 250*250 | 250*250 |
| Cabinet Size(mm*mm*mm) | 500*500/500*1000 | 500*500/500*1000 | 500*500/500*1000 | 500*500/500*1000 |
| Cabinet Resolution(dot*dot) | 192*192/192*384 | 168*168/168*336 | 128*128/128*256 | 104*104/104*208 |
| Cabinet Material | Die-cast Aluminum | Die-cast Aluminum | Die-cast Aluminum | Die-cast Aluminum |
| Cabinet Weight(kg) | 8/13 | 8/13 | 8/13 | 8/13 |
| Brihtness(cd/㎡) | 3500~4000 | 3500~4000 | 3500~4000 | 3500~4000 |
| Refresh Rate(hz) | 1920~3840 | 1920~3840 | 1920~3840 | 1920~3840 |
| Gray Scale(bit) | 14 | 14 | 14 | 14 |
| Viewing Angle(deg) | H 160/V140 | H 160/V140 | H 160/V140 | H 160/V140 |
| Max Power Consumption(w/㎡) | 440 | 440 | 440 | 440 |
| Ave Power Consumption(w/㎡) | 132 | 132 | 132 | 132 |
| Input Voltage(V) | 100~240 | 100~240 | 100~240 | 100~240 |
| Working Temperature(℃) | -20~+60 | -20~+60 | -20~+60 | -20~+60 |
| Operation Humidity(rh) | 10%~90% | 10%~90% | 10%~90% | 10%~90% |
| Ingress Pritection | IP65 | IP65 | IP65 | IP65 |
| Working Environment | Outdoor | Outdoor | Outdoor | Outdoor |
| Life Span(H) | 100,000 | 100,000 | 100,000 | 100,000 |
| Certificate | CE/ETL/FCC | CE/ETL/FCC | CE/ETL/FCC | CE/ETL/FCC |
|
|
