| Brand Name : | TEWEI |
| Model Number : | K |
| Certification : | ETL FCC EMC LVD |
| Price : | USD 600-1200/SQM |
| Payment Terms : | T/T |
| Supply Ability : | 1000 SQM |
| Delivery Time : | 30 day |
Rental LED Screen P3.91 High Refresh Rate Led Screen For Meeting Rooms Concerts Church
Modular design
Front & rear access on both LED module and power box
-10°~10°curve installation
90°degree right angle cabinet available
Smart module
High refresh rate:3840HZ
| Model | TW-K 1.9 i | TW-DF2.6o | TW-DF3.9o |
| Pixel Pitch(mm) | 1.9 | 2.6 | 3.9 |
| Pixel Density(dot/㎡) | 262,144 | 112,896 | 65,536 |
| LED Type | SMD1515 | SMD1415 | SMD1921 |
| Module Size(mm*mm) | 250*250 | 250*250 | 250*250 |
| Module Resolution(dot*dot) | 128*128 | 96*96 | 64*64 |
| Cabinet Size(mm*mm*mm) | 500*500 | 500*1000 | 500*1000 |
| Cabinet Resolution(dot*dot) | 256*256 | 192*384 | 128*256 |
| Cabinet Material | Aluminum | Aluminum | Aluminum |
| Cabinet Weight(kg) | 13 | 13 | 13 |
| Brihtness(cd/㎡) | 800~1000 | 800~1000 | 800~1000 |
| Refresh Rate(hz) | 3840 | 3840 | 3840 |
| Gray Scale(bit) | 14 | 14 | 14 |
| Viewing Angle(deg) | H 160 /V140 | H 160 /V140 | H 160 /V140 |
| Max Power Consumption(w/㎡) | 440 | 800 | 800 |
| Ave Power Consumption(w/㎡) | 130 | 240 | 240 |
| Input Voltage(V) | 100~240 | 100~240 | 100~240 |
| Working Temperature(°C) | -20～+60 | -20～+60 | -20～+60 |
| Operation Humidity(rh) | 10%-~90% | 10%-~90% | 10%-~90% |
| Ingress Pritection | IP21 | IP65 | IP65 |
| Working Environment | Indoor | outdoor | outdoor |
| Life span(H) | 100,000 | 100,000 | 100,000 |
| Certificate | CE/ETL/FCC | CE/ETL/FCC | CE/ETL/FCC |
Fast Assembly
Fast lock and single operator handle are adopted for the cabinet
connection.
It only takes 8 seconds to connect a single cabinet.
Equipped with positioning pins to assist alignment in ensuring the
installation speed and connection accuracy.
Anti-Collision Design
Four corner protectors are around the corner to prevent the module
from being damaged during transportation
Two bottom plates are designed to avoid the cabinet in direct
contact with the ground.
Creative Shape
High precision arc lock supports -5°, -2.5°, 0°, +2.5°, and +5°
It can realize a variety of shapes like concave, flat, and convex
FAQ
Q1. What is your terms of packing?
A:Usually, we pack our goods in neutral wooden cases and flight
cases. If you have a legally registered patent, we can pack the
goods in your branded boxes after getting your authorization
letter.
Q2. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the
photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW
Q4. How about your delivery time?
A: Generally, it will take 15 to 20 days after receiving your
advance payment. The specific delivery time depends on the item and
your order quantity.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We
can build the molds and fixtures.
|
|
