Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color LED Panel

Shenzhen Tewei Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color LED Panel from wholesalers

    Buy cheap Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color LED Panel from wholesalers
    • Buy cheap Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color LED Panel from wholesalers
    • Buy cheap Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color LED Panel from wholesalers
    • Buy cheap Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color LED Panel from wholesalers
    • Buy cheap Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color LED Panel from wholesalers
    • Buy cheap Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color LED Panel from wholesalers

    Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color LED Panel

    Ask Lasest Price
    Brand Name : TEWEI
    Model Number : Doiphin P4.8
    Certification : CE RoHS ISO9001 UL CCC ETL FCC EMC LVD
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 1000 SQM
    Delivery Time : 30 day
    • Product Details
    • Company Profile

    Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color LED Panel

    Outdoor LED Screen SMD1921 P4.8mm Outdoor Fixed LED Display Full Color P4.8 LED Panel


    Outdoor Fine Pitch Fixed Installation


    High brightness Up To 6500CD-7000CD


    Totally front & rear service


    Fast heat dissipation


    IP65 protection level


    Product Parameter Table


    ModelTW-DP 2.9TW-DP 3.9TW-DP 4.8
    Pixel Pitch(mm)2.93.94.8
    Pixel Density(dot/㎡)112,89665,53643,264
    LED TypeSMD1415SMD1921SMD1921
    Module Size(mm*mm)250*250250*250250*250
    Module Resolution(dot*dot)84*8464*6452*52
    Cabinet Size(mm*mm*mm)500*1000*80500*1000*80500*1000*80
    Cabinet Resolution(dot*dot)168*336128*256104*208
    Cabinet MaterialAluminumAluminumAluminum
    Cabinet Weight(kg)16/1216/1216/12
    Brihtness(cd/㎡)4500~50004500~70004500~7000
    Refresh Rate(hz)1920~38401920~38401920~3840
    Gray Scale(bit)141414
    Viewing Angle(deg)H 160 /V140H 160 /V140H 160 /V140
    Max Power Consumption(w/㎡)800800800
    Ave Power Consumption(w/㎡)240240240
    Input Voltage(V)100~240100~240100~240
    Working Temperature(°C)-20~+60-20~+60-20~+60
    Operation Humidity(rh)10%-~90%10%-~90%10%-~90%
    Ingress PritectionIP65IP65IP65
    Working EnvironmentOutdoorOutdoorOutdoor
    Life span(H)100,000100,000100,000
    CertificateCE/ETL/FCCCE/ETL/FCCCE/ETL/FCC



    Supporting Multiple Cabinet Sizes

    super adaptable to requests on various screen dimensions

    500*1000mm
    500*750mm
    500*500mm

    All materials supporting both front&rear maintenance,

    super adaptable to various installation environments



    Fast lock system shorten installation time to save labor cost




    FAQ

    Q1. What is your terms of packing?


    A:Usually, we pack our goods in neutral wooden cases and flight cases. If you have a legally registered patent, we can pack the goods in your branded boxes after getting your authorization letter.


    Q2. What is your terms of payment?


    A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.


    Q3. What is your terms of delivery?


    A: FOB


    Q4. How about your delivery time?


    A: Generally, it will take 15 to 20 days after receiving your advance payment. The specific delivery time depends on the item and your order quantity.


    Q5. Can you produce according to the samples?


    A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.


    Q6. What is your sample policy?


    A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.


    Q7. Do you test all your goods before delivery?


    A: Yes, we have 100% test for 72hrs before delivery.


    Q8: How do you make our business long-term and good relationship?


    A:1. We keep good quality and competitive price to ensure our customers benefit ;


    2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.


    Q9: What is your best service?


    1: One to one sales engineer to customer responsibility system; 2. Know your project and provide the best solution for it;, 3. Track your order and let you know each step and detail of it; 4. Teach you how to install and use the screen; 5. Care the subsequent use of your screen and ensure your after - sales service be well.


    Q10:How about your Warranty Term?


    A: 2-year warranty. Structure design, installation problem, system problem, how to use the screen... don't worry, we have professional after-sale team to solve your any questions after you placed an order. And your exclusive sales engineer will also help you get over any problems.
