Top-class LED Display Manufacturer in China. services more than 120 countries around the world!
2 Years
| Ask Lasest Price | |
| Brand Name : | TEWEI |
| Model Number : | P8.33 |
| Certification : | CE RoHS ISO9001 UL FCC CCC |
| Price : | Negotiation |
| Delivery Time : | 20-25 days |
| Model | P4.16 | P5 | P6.25 | P8.33 | P10 |
| Pixel Pitch(mm) | P4.16 | P5 | P6.25 | P8.33 | P10 |
| LED Type | SMD1921 | SMD1921 | SMD2727 | SMD2727 | SMD2727 |
| Pixel Density(dot/㎡) | 57600 | 40000 | 25600 | 14400 | 10000 |
| Module Resolution | 96X72 | 80X60 | 64X48 | 48X36 | 40X30 |
| Module Size(mm*mm) | 400X300 | 400X300 | 400X300 | 400X300 | 400X300 |
| Module composition(WxH) | 4X3 | 4X3 | 4X3 | 4X3 | 4X3 |
| Cabinet Resolution(dot*dot) | 384x216 | 320x180 | 256x144 | 192x108 | 160x90 |
| Cabinet Size(mm*mm*mm) | 1600X900X98 | 1600X900X98 | 1600X900X98 | 1600X900X98 | 1600X900X98 |
| Cabinet Flatness(mm) | ≤ 0.1 | ≤ 0.1 | ≤ 0.1 | ≤ 0.1 | ≤ 0.1 |
| Maintenance Way | Front Maintenance & Rear Maintenance | ||||
| Brightness (nits) | 6500 | ||||
| ColorTemperature (K) | 3200-9300 adjustable | ||||
| Gray Scale | 65536 | ||||
| Contrast | 5000:1 | ||||
| Frame Rate (Hz) | 50/60 | ||||
| Driving Mode | Constant current drive,1/6 Scan | ||||
| Cabinet Material | Aluminum | ||||
| Cabinet Weight(kg) | 5.8/4.6 | ||||
| Refresh Rate(hz) | 3840 | ||||
| Gray Scale(bit) | 14 | ||||
| Viewing angle(horizontal/vertical) | 160°/140° | ||||
| Max Power Consumption(w/㎡) | 600-800 | ||||
| Ave Power Consumption(w/㎡) | 100-200 | ||||
| Input Voltage(V) | 100~240 | ||||
| Working Temperature(℃) | -20~+60 | ||||
| Operation Humidity(rh) | 10%~90% | ||||
| Ingress Pritection | IP65 | ||||
| Working Environment | Outdoor | ||||
| Life Span(H) | 100,000 | ||||
| Certificate | CE/ETL/FCC | ||||
|
|
