Top-class LED Display Manufacturer in China. services more than 120 countries around the world!
2 Years
| Ask Lasest Price | |
| Brand Name : | TEWEI |
| Model Number : | JF-3.9-7.8 |
| Price : | $1,079.00/sets 1-49 sets |
| Payment Terms : | T/T |
| Supply Ability : | 4000 Set/Sets per Month |
| Delivery Time : | 25 days after receiving the deposit or full payment |
| Model | JF 2.6-5.2 | JF 3.91-7.81 | JF 7.81-7.81 |
| Pixel Pitch(mm) | P2.6-5.2 | P3.91-7.81 | P7.81-7.81 |
| Pixel Density(dot/㎡) | 73,728 | 32,768 | 16,834 |
| Module Size | 500X125mm | 500X125mm | 500X125mm |
| Module Resolution(mm*mm) | 192x24 | 128x16 | 64x16 |
| Cabinet Size(mm*mm*mm) | 1000mm*1000mm*82mm/1000mm*500mm*82mm | ||
| Cabinet Resolution(dot*dot) | 384x96 | 256x64 | 128x64 |
| Cabinet Material | Aluminum | ||
| Transparancy | >42% | >65% | >65% |
| Cabinet Weight(kg) | 10 | ||
| Brihtness(cd/㎡) | 800-4500CD | ||
| Refresh Rate(hz) | ≥1920Hz | ||
| Gray Scale(bit) | 14 | ||
| Viewing Angle(deg) | H 160/V140 | ||
| Max Power Consumption(w/㎡) | 800 | ||
| Ave Power Consumption(w/㎡) | 270 | ||
| Input Voltage(V) | 100~240 | ||
| Working Temperature(℃) | -20~+60 | ||
| Operation Humidity(rh) | 10%~90% | ||
| Ingress Pritection | IP31 | ||
| Working Environment | Indoor | ||
| Life Span(H) | 100,000 | ||
| Certificate | CE/ETL/FCC | ||
|
|
