| Brand Name : | TEWEI |
| Model Number : | P9.5 |
| Certification : | CE RoHS ISO9001 UL FCC CCC |
| Price : | Negotiation |
| Delivery Time : | 20-25 days |
Applications :
| Model | P4.7 | P6.3 | P9.5 |
| Pixel Pitch(mm) | 4.7625mm | 6.35mm | 9.525mm |
| Pixel Density(dot/㎡) | 44100 | 24649 | 11025 |
| LED Type | SMD1921 | SMD2727 | SMD2727 |
| Module Size(mm*mm) | 1ft*2ft (304.8x609.6mm) | ||
| Module Resolution(dot*dot) | 64 x 128 | 48 x 96 | 32 x 64 |
| Driving Mode | 1/8 scan | 1/6 scan | 1/2 scan |
| Module Pixels | 8192 | 4608 | 2048 |
| Cabinet Size(mm*mm*mm) | 1ft*2ft (304.8x609.6mm) | ||
| Cabinet Resolution(dot*dot) | 64 x 128 | 48 x 96 | 32 x 64 |
| Cabinet Material | Aluminum | ||
| Minimum ViewingDistance | ≥4m | ≥6m | ≥9m |
| Cabinet Weight(kg) | 8.6lbs / 3.9kgs | ||
| Brihtness(cd/㎡) | 6000-7000 | 6000-9000 | 6000-10000 |
| Refresh Rate(hz) | 1920Hz~3840Hz | ||
| Gray Scale(bit) | 13-24 | ||
| Viewing Angle (HA) | H:160°/V:160° | ||
| Max Power Consumption(w/㎡) | 800 | ||
| Ave Power Consumption(w/㎡) | 230 | ||
| Input Voltage(V) | AC110V-AC220V@ 50Hz/60Hz | ||
| Working Temperature(℃) | -20℃~45℃ | ||
| Operation Humidity(rh) | 10% ~ 90% | ||
| Ingress Pritection | IP67 | ||
| Working Environment | Outdoor | ||
| Life Span(H) | 100000 | ||
| System | Windows (win8, Win10 etc.) | ||
| Signal Source Compatibility | DV,HDMI13.DP1.2.SD1.HDMI2.0.etc. | ||
| Certificate | CE/ETL/FCC | ||
|
|
